Fmuser IPTV HD STB
4K VP9 Video decoder, 4K 10-bits H.265/H.264 video decoder. 1080P other video decoders (VC-1, MPEG-1/2/4, VP6/8). H.263/H.264 2160P@ 24fps.
Key Specifications
- Video decoding 4K VP9 Video decoder, 4K 10-bits H.265/H.264 video decoder
- Video Decoder format H.264,H.265,VP8,MVC(1080P)
- Power Supply DC input 5V/2A
- Picture format Supports JPG, JPEG, BMP, GIF, PNG, JFIF etc Resolution 8192x8192
- HDMI Including an HDMI 2.0 for HDMI 2.0 for 4K YUV420@60Hz with HDCP 1.4/2.2
- Video format Supports DIVD/DIVX/REAL8 / 9 / 10, RV, RM, RMVB, PMP, FLV, MP4, M4V, VOB, VP6, VP8 2160P @ 24fps
- Audio format Supports MP1, MP2, MP3, WMA, OGG, AAC, M4A , FLAC, APE, AMR, RA, WAV, etc
- Stream In/Out 1*HDMI 2.0
Overview
Key Features: Personalized EPG interface for hotel, hospital, Community and other industries.; System wallpaper is changeable and EPG content is editable.; Various business modes blend in IPTV system; Support modular interface and convenient to docking with third part manage software; Hotel, hospital and community version can support set up advertisement business to increase revenues.; Ad modes include booting ad, Menu ad (only for hospital and community version), VOD ad, pictures and text ad etc.; 1080P/60Hz full HD video; Mass resource of Video on Demand including movies, entertainments, factual shows and etc; Live programs synchronized broadcast; Fmuser IPTV system is with solid quality based on Fmuser’s own DTV head-end equipment; The whole system is self research and developed, which makes it easy for the after-sale maintenances; Skilled after-sale supporting team Specifications: 4K VP9 Video decoder, 4K 10-bits H.265/H.264 video decoder; Built-in HDMI 2.0 transmitter including both controller and PHY with CEC and HDCP, 4K @ 60FPS max resolution output; 1080P other video decoders (VC-1, MPEG-1/2/4, VP6/8); Video Decoder format; Video post processor: de-interlace
Technical Specifications
Encoding & Decoding
Video
| Video format | Supports DIVD/DIVX/REAL8 / 9 / 10, RV, RM, RMVB, PMP, FLV, MP4, M4V, VOB, VP6, VP8 2160P @ 24fps |
Audio
| Audio format | Supports MP1, MP2, MP3, WMA, OGG, AAC, M4A , FLAC, APE, AMR, RA, WAV, etc |
Processing Features
| Support Subtitle | SRT, SMI, SUB, SSA, IDX+USB |
Codec Settings
| Video decoding | 4K VP9 Video decoder, 4K 10-bits H.265/H.264 video decoder |
| Video Decoder format | H.264,H.265,VP8,MVC(1080P) |
IP Streaming
| HDMI | Including an HDMI 2.0 for HDMI 2.0 for 4K YUV420@60Hz with HDCP 1.4/2.2 |
| WiFi | 2.4G，802.11 b/g/n, |
| Stream In/Out | 1*HDMI 2.0 |
| 1* SD Card | to 64GB |
System & Physical
Power
| Power Supply | DC input 5V/2A |
Management
| Hardware | CPU |
| GPU | ARM Mali-400 GPU |
| Memory | 1GB DDRIII |
| Flash | 8GB Nand Flash |
| Wired network | Ethernet GMAC 10/100/100M Ethernet controller |
| Picture format | Supports JPG, JPEG, BMP, GIF, PNG, JFIF etc Resolution 8192x8192 |
| HDD file system | FAT16 / FAT32 / NTFS |
| XBMC/KODI | Support |
| DRM | Widewine Level1, DRM PlayReady ,Verimatrix, built in Trustzone,HDCP 2.2/1.4 |
| Support language | Chinese, English, Germany, Japanese, Korea etc. multilateral languages |
